Allis-Chalmers 5020 - 5030 Compact Diesel Tractor Operator's Manual

88 Pages

This Manual is available in: Digital Download

CONTENTS

TO OUR CUSTOMER

USER'S RESPONSIBILITY - WARRANTY - ALLIS CHALMERS

METRIC INFORMATION

BATTERY SERVICE ADJUSTMENT POLICY

CONTENTS

SAFETY

SPECIFICATIONS

LUBRICATION AND SERVICE

• Time Interval Chart for Service Items
• Lubrication and Service Guide
• Fuels
• Front Axle
• 3-Point Hitch
• Clutch - Brake Shaft Assembly
• Engine Cooling System
• Checking Engine Oil Level
• Engine Oil Filter
• Engine Fuel Sediment Bowl and Filter
• Bleed Air From Fuel System
• Transmission and Hydraulic System Oil
• Battery
• Fuel Tank
• Air Cleaner, Cup and Element
• Alternator
• Injection Pump Lubrication
• Engine Service Tips
• Storage of Tractor
• Tires
• Tire Pressure and Load Table
• Wheel Bolt Torque
• Weighing Tractor
• How to Order Parts

OPERATING CONTROLS AND INSTRUMENTS

OPERATION

• Starting and Stopping Engine
• Fast Warm-up Period
• Break-In Period
• Engine Clutch Pedal
• Gear Shifting - Transmission
• Coasting
• Brake Pedals and Lock Lever
• PTO Shaft
• Safety Tips and PTO Operating Instruments
• Drawbar - 3 Point Hitch
• Links
• Hitching to Implement

ADJUSTMENTS

• Position Control Lever Friction
• Lowering Speed
• Fan Belt
• Engine Clutch Pedal
• PTO Shift Lever
• PTO Safety Start Switch
• Brake Pedal
• Front Wheel & Rear Wheel Tread (5020)
• Front Wheel & Rear Wheel Tread (5030)
• Operator's Seat

WIRING DIAGRAM

• Liquid Ballast

MISCELLANEOUS, OPTIONAL, AND EXTRA EQUIPMENT

• ROPS Frame (5020)
• ROPS Frame (5020) FWD
• ROPS Frame (5030)
• Single Front Weights
• Stacked Front Weights
• Stacked Rear Weights

Manual Code: 2097271
