Allis-Chalmers 7580 Diesel Tractor - Operator's Manual

  • $1399


Allis-Chalmers 7580 Diesel Tractor Operator's Manual

100 Pages

This Manual is available in: Digital Download

Serial No. 2001 and up

CONTENTS

TO OUR CUSTOMER

USER'S RESPONSIBILITY - WARRANTY

BATTERY ADJUSTMENT POLICY

SAFETY

GENERAL INFORMATION

SERIAL NUMBER LOCATIONS

SPECIFICATIONS

GROUND SPEED CHARTS

METRIC EQUIVALENTS

LUBRICATION AND SERVICE

  • Time Interval Chart f/Service Items
  • Engine Oil
  • Lubrication and Service Guide
  • Diesel Fuel
  • Rules for Handling Fuels
  • Fuel Storage
  • Tractor Fuel Tank Filler Cap
  • Cooling System
  • Cooling System Conditioner
  • Engine Oil
  • Engine Oil Filters
  • Transmission & Drop Box Oil
  • Transmission & Drop Box Filter
  • Front Axle Housing Oil
  • Pinion Bearing Lube Tube Screen
  • Differential and Final Drive Oil
  • Differential and Final Drive Oil Filters
  • Three·Point Hitch· Lube
  • Wide Swing Drawbar - Lube
  • Steering & Pivot - Lube
  • Hinge Lock
  • Drive Shafts - Lube
  • Alternator
  • Batteries
  • Servicing Air Cleaner Element
  • Inspecting the Cleaned Filter Element
  • Inspecting Air Induction System
  • Reinstalling the Filter Element
  • Safety Filter Element
  • Fuel Filter
  • To Bleed The System
  • Crankcase Breather Tube
  • The Turb ocharger
  • Traction Booster Linkage
  • Tractor Storage
  • Cooling Cores
  • Service Tips

OPERATING CONTROLS AND INSTRUMENTS

  • Temperature & Fuel Gauge
  • Alt ernator Warning Light
  • Engine Oil Pressure Warning Light
  • Transmission Oil Temperature Warning Light
  • Rear Housing Oil Temperature Warning Light
  • Turn Signal Indicator
  • Hydraulic Oil Filter Warning Light
  • Transmission Oil Pressure Warning Light
  • Transmission Oil Filter Warning Light
  • Operation Meter
  • Ke y Switch,
  • Warning Light Check
  • Engine Start Switch
  • Light Switch
  • Fuel Shut off
  • Throttle Lever
  • Flashing Safety Warning Lights
  • Red Reflectors
  • Rear Flood Lights on Wheel Guard
  • Transmission Gear Shift Lever
  • Power Director ill & LO Shift Buttons
  • Clutch Pedal
  • Brake Pedal
  • Foot Throttle
  • Steering Wheel Tilt Lever
  • Power Steering
  • Operator's Seat
  • Safety Belt
  • Range Transmission Shift Lever
  • Position Control Lever
  • PTO Clutch Lever
  • Traction Booster Control Lever
  • Remote Cylinder Control Levers
  • Remote Cylinder Outlet Flow Control Adjustment
  • Tractor Cab Controls
  • Air Filter3
  • Cab Pressurizer
  • Heater & Air Conditioner
  • Windshield Wiper Switch
  • Rear View Mirror
  • Fuel Tank
  • Universal Symbols

OPERATION

  • Starting the Engine
  • Diesel Starting Fluid
  • Fast Warm-up Period
  • Stopping The Engine
  • Starting Group Travel
  • Towing Tractor
  • Break-in Period
  • Drawbar - Three-Point Hitch
  • Three-Point Hitch
  • Sway Blocks
  • Draft Arms
  • Lift Links
  • Upper Link - Beaming Tube
  • Quick Hitch Coupler
  • Modifying Implement Hitch
  • Attaching Implement to Quick Hitch
  • Removing Implement from Quick Hitch
  • Wide Swing Drawbar
  • PTO Operation
  • Tires
  • Weighting the Tractor
  • Implements & Attachments
  • Attachments Other Than Drawbar or-Point Equipment

ADJUSTMENTS

  • Door Stop Link & Latch
  • Battery Retainer Adjustment
  • Torsion Bar Preload Adjustment
  • Traction Booster Linkage Adjustment
  • Sensitivity Adjustment
  • Hand Lever Friction Adjustment
  • Pressure Release Adjustment
  • Remote Flow Control Adjustment
  • Valve Lash
  • Fan Belt3
  • Wheel Treads (power Shift)
  • Wheel Treads (Non-Power Shift)
  • Rim & Wheel Combination
  • Wheel Bushing Torque
  • Clutch Pedal Safety Start Switch
  • PTO Safety Start Switch
  • Air Conditioner Belt

WIRING DIAGRAMS

MISCELLANEOUS, OPTIONAL & EXTRA EQUIPMENT

  • Liquid Ballast in Tractor Tires
  • Wheel Weights
  • Wheel Guards3
  • Roll Over Protective Cab w/Pressurizer
  • Reinstallation of ROPS Cab
