Farmall and International GSS-1010-B Tractors Fuel System Diesel Engine Models D-236, D-282, and D-301

  • $1999


Farmall and International GSS-1010-B Tractors Fuel System Diesel Engine Models D-236, D-282, and D-301 Blue Ribbon Service Manual

82 Pages

This Manual is available in: Digital Download

CONTENTS

Specifications

General Description and Operation

  • Filter System
  • Factors Affecting Pump and Nozzle Life
  • The Injection Pump
  • Load Advance
  • Automatic Speed Advance (Later Model)

Iniection Nozzles and Precombustion Chambers

Trouble Shooting

Checks and Adjustments

  • Fuel Shut-Off Adjustment
  • Governor Linkage Hook Adjustment
  • High and Low Idle Speed Adjustment
  • Governor Control Adjustment
  • Transfer Pump Adjustments
  • Air Leaks in Suction Side of Fuel System
  • Inefficient Transfer Pump or Malfunctioning Pressure Regulating Valve
  • Transfer Pump Pressure
  • Fuel Return Line Plugged or Restricted
  • Delivery Valve and Rotor Check
  • Broken Delivery Valve Spring
  • Pump Timing and Rotor Rotations
  • Load Advance Adjustment
  • Speed Advance Adjustment
  • Glow Plugs
  • Compression Pressure
  • Torque Screw Adjustment
  • Leaf-Spring Adjustment

Injection Pump Service

  • Pump Removal
  • Drive Shaft Removal
  • Pump Disassembly
  • End Plate Assemblies
  • Inspection and Repair
  • Reassembly
  • Pump Drive Shaft and Injection Pump Installation

Injection Nozzle and Pre-combustion Chamber Service

  • Bosch - Model ADE
  • Removal
  • Testing
  • Preliminary Inspection
  • Disassembly
  • Inspection and Repair
  • Reassembly and Testing
  • Installation
  • IH Midget or Micro Nozzles
  • Disassembly
  • Inspection and Repair
  • Reassembly
  • Testing
  • Pre combustion Chambers

Priming Pump

Induction System Service

Special Service Tools

Manual Code: GSS-1010-B
