INTERNATIONAL 886, 986, 1086, 1486, 1586, and HYDRO 186 TRACTORS - Operator's Manual

In stock
Regular price $19.99 inc. VAT
Title

INTERNATIONAL 886, 986, 1086, 1486, 1586, and HYDRO 186 TRACTORS Operator's Manual

114 Pages

This Manual is available in: Digital Download

CONTENTS

TO THE OWNER

SERIAL NUMBERS

WORK SAFELY - FOLLOW THESE RULES

  • Servicing and Before Starting
  • Starting
  • During Operation
  • Transporting
  • Tractors with Cabs
  • Before Dismounting
  • Dismounting
  • After an Upset

INSTRUMENTS AND CONTROLS

  • Instrument Panel and Controls
  • Left and Right Console, and Hydraulic Seat Controls
  • Seat Controls
  • Cab Interior

BEFORE OPERATING YOUR TRACTOR

OPERATING THE TRACTOR

  • Neutral Starting Switch
  • Starting the Engine
  • Stopping the Engine
  • With the Engine Running
  • Steering the Tractor
  • Starting the Tractor (Gear Drive)
  • Hydraulic Powered Clutch Control (Gear Drive)
  • Stopping the Tractor (Gear Drive)
  • Starting the Tractor (Hydrostatic Drive)
  • Stopping the Tractor (Hydrostatic Drive)
  • Speedometer-Tachometer
  • Digital Tachometer-Speedometer
  • Selecting Ground Speeds (Gear Drive)
  • Torque Amplifier (Gear Drive)
  • Park Lock Lever
  • Selecting Ground Speeds (Hydrostatic Drive)
  • Starting Procedure for Hydrostatic Drive Tractors After Transporting on Truck or Flatcar
  • Towing the Tractor
  • Tractor Break-In Procedure

CAB INTERIOR AND CONTROLS

  • Operating the Controls
  • Control Settings
  • Radio Units
  • Seat

ENGINE AND FUEL SYSTEM

  • Warranty Notice
  • Fuel System
  • Fuel Injection Pump and Nozzles
  • Priming the Turbocharger
  • Changing the Ether Fluid Container

COOLING SYSTEM

  • Coolants
  • Cooling System Conditioner
  • Checking the Coolant Level
  • Draining and Filling the Cooling System
  • Hoses and Clamps Cleaning the Cooling System
  • Thermostat
  • Cleaning the Radiator, Transmission Oil Cooler, and Condenser Core Fins
  • Cooling System Filter Conditioner
  • Water Pump, Alternator-Generator and Fan Belt Tension

AIR CLEANING SYSTEM

  • Removing and Cleaning the Primary Filter Element
  • Inspection
  • Secondary Filter Element
  • Automatic Dust Unloader

ELECTRICAL SYSTEM

  • Charging System for Alternator-Generator
  • Cranking System
  • Lighting System
  • Lights
  • Instrument Light Dimmer Switch
  • Turn Signal Indicators Combination Turn Signals and Warning Lights
  • Tellites
  • Fuse
  • Batteries

HYDRAULIC CONTROLS FOR THREE-POINT HITCH

  • Position Control
  • Position Control Lock Lever
  • Draft Control
  • Run Range

ALL-WHEEL DRIVE

DIFFERENTIAL LOCK

FRONT WHEELS

  • Adjustable Wide Tread Front Axle
  • Farmall Hi -Clear Adjustable Front Axle
  • All-Wheel Drive Front Axle
  • Tricycle Front Axle
  • Adjusting Wide-Tread Front Axle for Tread Widths
  • Adjusting the Toe-I n

THREE-POINT HITCH

  • Hitch Category Chart
  • Lift Links and Turnbuckles
  • Hitch Lower Links
  • Hitch Upper Links
  • Lateral Limiter
  • Lateral Limiter Adjusting Procedure
  • Sway Limiter Blocks
  • Lateral Limiter
  • Coupling the Equipment
  • Example of Operating the Three-Point Hitch with Draft Control
  • Uncoupling the Equipment

REAR WHEELS

  • Adjusting the Tread Widths
  • Assembling the Rear Wheel
  • Double-Beaded Rims
  • Reversing the Rear Wheels
  • Wheels With Fixed Rims
  • Wheels With Double-Beaded Rims
  • Wheels With Attached Clamp Rims
  • Tractors With Wedge Wheels
  • Wedge Wheels
  • Tractors With H u b Clamp Wheels
  • ual Rear Wheels

HITCHING TRAILING EQUIPMENT TO THE TRACTOR

  • Swinging Drawbar for Tractors Without Three-Point Hitch
  • Swinging Drawbar for Tractors With Three-Point Hitch

AUXILIARY VALVES, REMOTE CYLINDERS AND HYDRAULIC OUTLETS

  • Connecting Hoses to the Rear Hydraulic Outlets
  • Check Valves
  • Operating Double Acting Cylinders
  • Operating Single Acting Cylinders
  • Neutral Lock
  • Float Lockout
  • Adding Fluid After Connecting Cylinders and Hoses
  • Freeing the System of Trapped Air
  • Sequential Raise
  • Simultaneous Raise

POWER TAKE-OFF

  • Operating the Independent Power Take-Off

TIRES

  • Inflation
  • Front Tire Inflation Pressure
  • Rear Tire Inflation Pressure

WEIGHTS

  • Front End Weights
  • Front End Weight H old Down and Locking Device
  • All-Wheel Drive Tractors
  • Rear Wheel Weights (Two Piece)

COLD WEATHER PRECAUTIONS

  • Fuel System
  • Electrical
  • Lubrication
  • Cooling System

STORING THE TRACTOR

  • Storage
  • Removing From Storage

LUBRICATION

  • Engine Oil
  • Gear Lubricant
  • Lubrication Fitting Grease
  • Engine Oil Filter
  • Hydraulic Fluid Filter
  • Hydrostatic Drive Housing
  • Hydraulic Fluid Filter
  • Lubricating the Front Wheels

LUBRICATION TABLE

LUBRICATION GUIDE

PREVENTIVE MAINTENANCE GUIDE

CAB EQUIPMENT PREVENTIVE MAINTENANCE

  • Outside Air Filter
  • Recirculation Air Filter
  • Air Conditioner Condenser
  • Refrigerant Sight Glass
  • Refrigerant System Pressures
  • Evaporator Drain Valves
  • Adjusting the Compressor Belt Tension
  • Compressor Pulley and Clutch
  • Compressor Oil Level
  • Compressor Shaft Seal
  • Heater Coolant Shut-Off
  • Miscellaneous

SPECIFICATIONS

OPTIONAL EQUIPMENT

METRIC (SI) MEASUREMENTS

Manual Code: 1 084 462 R2. 2-77
