New Holland Hayliner 280 Balers - Owner's Manual

  • $1899


New Holland Hayliner 280 Balers Owner's Manual

52 Pages

This Manual is available in: Digital Download

CONTENTS

GENERAL INFORMATION

  • Warranty
  • A note to you Mr. Baler Owner
  • About improvements
  • Introduction
  • Contents
  • Specifications

OPERATION

  • Before using your baler
  • Attaching the baler to the tractor
  • Lubrication
  • Jack
  • Controls
  • Tongue shift
  • Belt tightener
  • Throttle control
  • Pickup lift
  • Starting the baler
  • Threading the baler
  • Bale weight
  • Bale length
  • Tying

SAFETY FEATURES

  • Flywheel shearbolt
  • Knotter drive shearbolt
  • Needle safety latch
  • Pickup drive slip clutch and overriding clutch
  • PTO drive slip clutch and overriding clutch
  • Auxiliary drive shearbolt

ADJUSTMENTS

  • Pickup wheel
  • Windguard
  • Pickup lift spring
  • Plunger Bearing and knife adjustment
  • Tine bar timing
  • Needle drive timing
  • Upper feed reel
  • Tooth pitch
  • Timing
  • Drive chain
  • Drive belts
  • Bale shape
  • Needles
  • Twine finger
  • Knotter brake
  • Metering wheel
  • Bale counter
  • Knotter
  • Twine disc
  • Twine holder
  • Bill hook
  • Knife arm
  • Removing end play from knotter stack

MAINTENANCE

  • Service adjustment chart
  • Engine care
  • Main gearbox
  • Tires
  • Belts
  • PTO
  • Needle safety latch
  • Pickup fingers
  • Pickup cam followers
  • Pick-up tooth pipe
  • Storing the baler
  • Safety precautions
  • Overheating switch
  • Special equipment
  • Hydraformatic bale tension control
  • Accumite

Manual Code: O280-3M-7-61W
