John Deere No 9 and No 9W Integral Mowers - Operator's Manual

  • $1199


John Deere No 9 and No 9W Integral Mowers Operator's Manual

50 Pages

This Manual is available in: Digital Download

CONTENTS

COMPLETE VIEW

SPECIFICATIONS

CROSS-SECTIONAL VIEW OF CHAIN DRIVE HOUSING

LUBRICATION

OPERATION

  • Starting Mower in the Field
  • Operating Speed
  • Number of Acres Cut per Hour
  • Turning Corners
  • Transporting
  • Safety Spring Release
  • Storing for Winter
  • Attaching Mower to Tractor
  • Disconnecting Mower from Tractor
  • Safety Suggestions

ADJUSTMENTS AND SERVICE

  • Chain Drive Housing
  • Cutter Bar Repair
  • Knife Alignment and Outer Shoe Stripper Plate Adjustment
  • Cutter Bar Tilt Adjustment
  • Adjustable Subsoles
  • Pitman
  • Grass Board and Stick
  • Pull Bar
  • Registering Knife
  • Cutter Bar" Alignment
  • Lifting Chain and Swivel Adjustment
  • Float Spring
  • Speed of Knife
  • Shielded Powershaft
  • Common Mower Troubles and Their Causes
  • Special Equipment

TRACTOR HOOKUP SHIPPING PACKAGES

ASSEMBLY

  • Attaching Hookup Parts Onto Mower
  • Hookup Sequence
  • Attaching Cutter Bar
  • Installing Knife
  • Attaching Pitman and Grass Board
